Cicada Audio CXK69 (2Ω or 4Ω) 6X9-inch Mid-Bass 2-Way Component Speaker Kit Fits 6×9 lids for 14-23 Does not fit 23.5-24 HD Lids
CXK69.4
$849.99
A high-output 6×9 mid-bass and tweeter component kit for bagger builds that need strong rear-stage output, clean mid-bass impact, and bright detail. ChromeVolt recommends final 2Ω/4Ω selection based on amplifier configuration and full system design.
Additional information
| Choose Ω | 2Ω, 4Ω |
|---|
Specs
- Configuration: 6×9-inch mid-bass component speaker kit
- Impedance availability: 4Ω and 2Ω versions
- Mid-bass driver: 6×9-inch mid-bass
- Mid-bass power handling: 250W RMS / 500W MAX
- Mid-bass voice coil: 2-inch / 51mm
- Mid-bass cone: Carbon Matrix Composite™
- Mid-bass magnet: Neodymium
- Mid-bass sensitivity: 94 dB, 1W / 1M
- Mid-bass frequency response: 70 Hz – 10 kHz +/- 3 dB
- Mid-bass mounting depth: 3.26-inch / 83mm
- Mid-bass mounting diameter: 5.7-inch / 145mm x 8.5-inch / 216mm
- Tweeter: 1-inch shallow ring radiator horn tweeter
- Tweeter power handling: 50W RMS / 100W MAX
- Tweeter voice coil: 1-inch / 25mm
- Tweeter dome: Aluminum
- Crossover: 12 dB @ 7 kHz
- Tweeter sensitivity: 101 dB, 1W / 1M
- Tweeter frequency response: 2 kHz – 20 kHz +/- 3 dB
- Tweeter mounting depth: 1.1-inch / 28mm
- Tweeter mounting diameter: 2-inch / 50.8mm
Features
- Rain or Shine™ all-weather performance design
- OFC copper shorting ring for extended high-frequency performance
- Carbon Matrix Composite™ cone for lightweight strength, heat resistance, and efficiency
- OFC copper wire voice coil with Black Coat™ for conductivity and thermal control
- N35SH neodymium magnet motor
- Die-cast aluminum custom-tooled basket with Vortex Flow Venting™
- Aluminum tweeter dome for bright detail and strong output
- Custom tooled, vented, encased external crossover
- Field-replaceable tweeter diaphragm
- Two-year manufacturer warranty
